  • butterfly valve
Read More About 1.5 inch foot valve

H42X-2.5 Lifting Foot Valve

Medium temperature: ≤50 ℃
Canolig: dwr
caliber: DN50-500mm
pressure: 0.25-0.6mpa
body material: gray cast iron
connection method: flange



lawrlwythiad i pdf
Manylion Cynnyrch
Tagiau Cynnyrch

PARAMEDRAU CYNNYRCH:

Enw Rhan deunydd
Corff falf grey cast iron
Bonnet grey cast iron
Disg grey cast iron
Modrwy selio rubber

Application: Widely used in the bottom end of the pipeline, it can automatically prevent liquid from flowing backward



model Pwysau enwol
(mpa)		 Pwysau prawf (mpa) tymheredd cywir Cyfrwng cymwys
nerth sêl
H42X-2.5 0.25  0.40  0.28  ≤50 ℃ dwr



model Diamedr enwol
(mm)		 Maint (mm)
H D Ch1 D2 bf z-φd
H42X-2.5 50 120 140 110 90 12-2 4 * φ14
65 135 160 130 110 12-2 4 * φ14
80 165 185 150 125 14-2 4 * φ18
100 175 205 170 145 14-2 4 * φ18
125 210 235 200 175 14-2 8 * φ18
150 250 260 225 200 16-3 8 * φ18
200 280 315 280 255 18-3 8 * φ18
250 390 370 335 310 18-3 12 * φ18
300 410 435 395 362 19-3 12 * φ23
350 520 485 445 412 25-3 12 * φ23

OUR ADVANTAGES：



1.Mae gennym dechnoleg castio Tywod neu Fanwl, Felly gallwn ni fel eich dyluniad lluniadu a chynhyrchu.

Mae logos 2.Customers ar gael wedi'u bwrw ar y corff falf.

3. ein holl castio gyda gweithdrefn dymheru cyn Prosesu.

4. Use the CNC lathe during whole process.

5. The disc sealing surface use plasma welding machine welding

6. Every valve must be tested before delivery from the factory, only qualified onescanbe shipped.

7.Y falf caredig rydym fel arfer yn defnyddio achosion pren i becynnu, Gallwn hefyd yn ôl
ceisiadau cwsmeriaid penodol.

COMPANY ADVANTAGES:

  • Read More About 1.5 inch foot valve
    1.Rydym yn wneuthurwr Ers 1992.
  • Read More About 1.5 inch foot valve
    2.CE, API, ISO wedi'i gymeradwyo.
  • Read More About foot valve hydrant
    Cyflwyno 3.Fast.
  • Read More About foot valve for water
    Pris 4.Low gydag ansawdd uchel.
  • Read More About foot valve hydrant
    Tîm gwaith 5.Professional!
