PRODUCT PARAMETERS:

ANSI Pipe Fittings Series Main production materials
Material name
ASTM A105, 20 #, Q235, 16Mn
ASTM A182 F304, F316, 316L, 321

Flange type		Thickness range		Caliber range		Implementation standards
elbow		SCH10-SCH160		1/2 "-48"		ANSI B16.9
Tee				1 1/2 "* 1 1/2" -24 "* 18"
Reducer				1 "* 3/4" -24 "* 22"
Tube cap				1/2 "-48"

ANSI Fittings

ANSI pipe fitting dimensions and connection dimensions
Long radius elbow
Nominal diameter (inches)	Outer diameter	Thickness (mm)
Nominal diameter (inches)	D	SCH10	SCH30	STD	SCH40	XS	SCH80
1/2	21.3	2.11	2.41	2.77	2.77	3.73	3.73
3/4	26.7	2.11	2.41	2.87	2.87	3.91	3.91
1	33.4	2.77	2.9	3.38	3.38	4.55	4.55
1 1/4	42.2	2.77	2.97	3.56	3.56	4.85	4.85
1 1/2	48.3	2.77	3.18	3.68	3.68	5.08	5.08
2	60.3	2.77	3.18	3.91	3.91	5.54	5.54
2 1/2	73	3.05	4.78	5.16	5.16	7.01	7.01
3	88.9	3.05	4.78	5.49	5.49	7.62	7.62
3 1/2	101.6	3.05	4.78	5.74	5.74	8.08	8.08
4	114.3	3.05	4.78	6.02	6.02	8.56	8.56
5	141.3	3.4	-	6.55	6.55	9.53	9.53
6	168.3	3.4	-	7.11	7.11	10.97	10.97
8	219.1	3.76	7.04	8.18	8.18	12.7	12.7
10	273.1	4.19	7.8	9.27	9.27	12.7	15.09

Tee
Nominal diameter (inches)	Outer diameter		STD		SCH40
Nominal diameter (inches)	D1	D2	t1	t2	t1	t2
1 1/2 * 1 1/2	48.3	48.3	2.77	2.77	2.77	2.77
2 * 3/4	60.3	26.7	3.91	2.87	3.91	2.87
*1	-	33.4	-	3.32	-	3.38
* 1 1/4	-	42.2	-	3.56	-	3.56
* 1 1/2	-	48.3	-	3.68	-	3.68
*2	-	60.3	-	3.91	-	3.91

Tube cap
Nominal diameter (inches)	Outside diameter D		E height	Limit thickness	Height E1	t
Nominal diameter (inches)	Hidemura	mm	E height	Limit thickness	Height E1	SCH40
1/2	0.84	21.34	25.4	4.57	25.4	0.109
3/4	1.05	26.67	25.4	3.81	25.4	0.133
1	1.315	33.4	38.1	4.57	38.1	0.133
1 1/4	1.66	42.2	38.1	4.83	38.1	0.14
1 1/2	1.9	48.2	38.1	5.08	38.1	0.145
2	2.375	48.3	38.1	5.59	44.5	0.154

Reducer
Nominal diameter (inches)	Outer diameter		STD		SCH40
Nominal diameter (inches)	D1	D2	t1	t2	t1	t2
1 * 3/4	33.4	26.7	3.38	2.87	3.38	2.87
1 1/2 * 3/4	48.3	26.7	3.68	2.87	3.68	2.87
*1	-	33.4	-	3.38	-	3.38
* 1 1/4	-	42.2	-	3.56	-	3.56
2 * 1	60.3	33.4	3.91	3.38	3.91	3.38
* 1 1/4	-	42.2	-	3.56	-	3.56

PRODUCT ADVANTAGES:

1.We have Sand or Precision casting technology,So we can as your drawing design andproduction.

2.Customers' logos are available cast on the valve body.

3. All our casting with tempering procedure before Processing.

4. Use the CNC lathe during whole process.

5. The disc sealing surface use plasma welding machine welding

6. Every valve must be tested before delivery from the factory, only qualified onescanbe shipped.

7.The kind valve we usually use Wooden cases to package,We also can according to
specific customer's requests.
